Vacuum casting/ Urethane Casting offers an economical solution for small batch production of plastic parts. By using silicone rubber molds and CNC or SLA parts as the main mold, we can accurately replicate details and textures, ensuring consistent finishes from one part to the next. This process allows us to simulate the final molded part or finished product, providing a cost-effective alternative to injection molding.
Product Advantage
Advantage
Description
High-Quality Parts
Vacuum casting produces parts with excellent surface finish and details.
Material Versatility
Compatible with a wide range of casting materials, including elastomers
Cost-Effective
Ideal for small-batch production, reducing tooling and setup costs
Quick Turnaround
Short lead times for producing functional prototypes and low-volume parts.
Complex Geometries
Ability to replicate intricate designs and complex geometries accurately.
Overmolding Capabilities
Enables the creation of parts withmulti-material and overmolded features.
Technical Parameters
Parameter
Value
Casting Material
Polyamide (PA)
Mold Material
Silicone
Tolerance
±0.1mm
Surface Finish
Smooth, matte
Casting Size Range
Small to medium parts
Vacuum Pressure
0.08-0.1 MPa
Curing Temperature
60-80°C
Curing Time
2-4 hours
Product Uses
● Prototyping and product development
● Small-batch production
● Functional testing
● Visual and aesthetic models
● Pre-production validation
Product Operate Guide
1. Prepare the Master Model: Create a high-quality master model using 3D printing or CNC machining techniques.
2.Mold Making: Build a silicone mold around the master model, ensuring it captures all the intricate details.
3.Mixing and Pouring: Prepare the PA casting material by mixing the resin with a hardener. Degas the mixture to remove air bubbles. Pour it into the mold.
4.Vacuum and Curing: Place the mold in a vacuum chamber to remove air bubbles. Cure the PA material in an oven or under UV light according to the specified temperature and time.
5.Demolding: Carefully remove the mold to reveal the casted part. Trim any excess material and perform post-processing if required.
6.Quality Control: Inspect the casted part for dimensional accuracy, surface finish, and any defects. Ensure it meets the desired specifications and quality standards.
7.By following these technical parameters and operating guidelines, vacuum casting provides a reliable and efficient method for producing high-quality prototypes and small-batch production parts in various industries.
